The Key to a Flawless Finish


Features

  • We don’t believe in charging for upgrades so we include all of the following & more on this amazing machine.
    • With its simple design, the Diamond11 can be rapidly installed and started. It can be
floor-anchored and does not require any foundations.
    • Simple manual adjustments make for easy operation and training.
  • Vertical edge polisher for polishing materials up to 60mm thick.
  • Equipped with an additional spindle which performs many profile shapes.
  • Spindle performs the edge profile shaping, or the thickness gauging, or the “drip board” carving.
  • Polishing spindle unit is designed with oscillating motion in order to guarantee the maximum polishing degree.
  • Polishing and chamfering spindles with pneumatic pressure, equipped with labyrinth frontal and protection bellows.
  • Great stability of the vertical piece thanks to the rigidity of the seat-guides and conveyor belt.
  • Simple manual adjustment of the lateral pressure bar according to the thickness of the piece to be worked.

Specifications

TECHNICAL DATA
  • Number of straight edge polish heads: 4
  • Number of profiling shape polish heads: 4
  • Number of heads for 45° chamfering polish: 3
  • Number of heads for 45° degree cutting and polishing: 1
  • Processing slab thickness: 4”
  • Minimum processing size: 7.87” x 3.94” x .59”
  • Maximum processing size: 78.74” x 78.74” x 4”
  • Gross power: 58kw, 200a
  • Water Consumption: up to 40gpm
  • Minimum working thickness – .4” (1 cm)
  • Maximum working thickness – 4” (8 cm)
  • Number of edge spindles – n° 5
  • Number of upper shaping spindles – n° 3
  • Number of lower shaping spindles – n° 3
  • Abrasives wheels diameter – 5” (130 mm)
  • Belt speed – 0-98.5 inches per minute
  • Dimensions (L x W x H): 321.44” x 45.18” x 85.02”, approx. 26.75’ x 3.75’ x 7’
  • Weight: 9920lbs
